Elbow

In a piping system, a elbow is a pipe fitting that changes the direction of the pipe.

Contact：Samantha Z

Phone：+8613583116312

Whatsapp/Wechat：+8613583116312

Email： google@s-materialgroup.com

Address: Yingsheng Steel Market, Fengnan District, Tangshan City, Hebei Province

Product Specifications

Product Details

In a piping system, a elbow is a pipe fitting that changes the direction of the pipe. According to the Angle, there are 45°,90° and 180° which are most commonly used, and other abnormal angle elbows such as 60° are also included according to engineering needs. Elbow materials are cast iron, stainless steel, alloy steel, malleable cast iron, carbon steel, non-ferrous metals and plastics.

					Theoretical weight kg/pcs
DN		OD	f	b	5s	10s	20s	40s	80s	120s
15	1/2	1821.3	38	16	0.040.05	0.050.06	0.0590.063	0.060.08	0.080.10
20	3/4	2526.7	38		0.060.06	0.070.08	0.080.09	0.090.10	0.130.13
25	1	3233.4	38	16	0.080.08	0.120.13	0.130.135	0,140.14	0.180.19
32	1.1/4	3842.2	48	20	0.110.13	0.180.21	0.210.24	0.230.26	0.310.35
40	1.1/2	4548.3	57	24	0.160.17	0.260.28	0.300.32	0.330.35	0.440.48
50	2	5760.3	76	32	0.280,2g	0.450.47	0.590.61	0.620.66	0.950.gn
65	2.1/2	7376.1	95	40	0.550.57	0.800.83	0.961.1	1.251.31	1.721.80
80	3	89	114	47	0.80	1.17	1.6	2.06	2.86
90	3.1/2	101.6	133	55	1.08	1.57	2.1	2.74	3.82
100	4	108114.3	152	63	1.311.39	1.012.03	2.652.87	3.543.76	5.135.46	6.276.68
125	5	133141.3139.7	190	79	2.682.822.87	3.243.453.41	4.815.125.06	6.166.546.47	8.719.259.14	11.312.011.9
150	6	159168.3165.2	229	95	3.854.104.03	4.694.964.87	6.977.387.24	9.5610.19.95	14.415.315.0	18.619.819.4

DN	OD		CD	Series A		Series B		NPS
DN	Series A	Series B	mm	Outer arc length	Inner arc length	Outer arc length	Inner arc length	NPS
15	21.3	18	38	76	42	73	45	1/2
20	26.9	25	38	81	38	76	40	3/4
25	33.7	32	38	86	33	84	34	1
32	42.4	38	48	108	42	105	45	1.1/4
40	48.3	45	57	127	51	124	54	1.1/2
50	60.3	57	76	166	72	164	74	2
65	76.1(73)	76	95	208	89	208	89	2.1/2
80	88.9	89	114	248	109	248	109	3
90	101.6	-	133	288	129	-	-	3.1/2
100	114.3	108	152	328	149	323	153	4
125	139.7	133	190	408	188	402	193	5
150	168.3	159	229	491	227	484	234	6
200	219.1	219	305	650	306	650	306	8
250	273.0	273	381	812	383	812	383	10
300	323.9	325	457	972	462	972	462	12
350	355.6	377	533	1115	652	1132	540	14
400	406.4	426	610	1276	638	1292	623	16
450	457.2	478	686	1435	718	1452	701	18
500	508.0	529	762	1595	797	1611	781	20
550	559	-	838	1754	876	-	-	22

Size	D	d	d1	d2	l	L
1/2"	29.5	17	21.54	21.23	24	37
3/4"	35	22	26.87	26.57	27	42.5
1"	43	29	33.65	33.27	30	48.5
1 1/4"	53	38	42.42	42.04	34	57.5
1 1/2 ”	59	44	48.56	48.11	37	65
2"	72	55	60.63	60.17	40	74
2 1/2“	88	67	73.38	72.85	47	88
3"	105	82	89.31	88.70	50	100
4"	132	106	114.76	114.1	60	122.5
5"	162	133	141.81	141.0	70	147.5
6"	191	160	168.83	168.0	80	172.5
8"	246	210	219.84	218.7	105	222.5
